Singer 14SH644 - 11. THREADING THE MACHINE; 1) Threading the Upper Looper (Orange)

12
Threading Diagram
Understanding the Color Code
To Thread The Machine Correctly
11. THREADING THE MACHINE
• A color coded threading diagram is located inside
the looper cover for quick reference.
• Thread the machine in the order 1 to 4 as shown.
Orange
Yellow
Green
Blue
1. Upper looper thread ...........
2. Lower looper thread ...........
3. Right needle thread ............
4. Left needle thread ..............
Caution :
Be sure to turn off power switch.
1) Threading the Upper Looper (Orange)
• Thread the upper looper as indicated 1 ~ 8 .
• Pass thread from back to the front through the
thread guide 1 .
1
3
4
2
1
1
2
3
4
5
8
7
6
