Singer 14SH644 User Manual

18
4) Threading the Left Needle (Blue)
• Thread the left needle as indicated 1 ~ 7 .
• Pass thread from back to the front through the
thread guide 1 .
• Thread the top cover thread
guide by pulling the thread
downward until it slips under
thread guide 2.
• While holding thread with finger, pass it between
the tension discs and pull thread down to make
certain it is properly located in between the
tension discs 3 .
3
1
2
3
4
5
6
7
1
2

Singer 14SH644 Specifications

General

Type	Automatic sewing machine
Free arm	Yes
Sewing speed	1300
Stitch width	Variable
Product color	White
Automatic buttonhole	-
Sewing machine functions	Overlock
Power supply type	Electromechanical

Weight and Dimensions

Width	320 mm
Height	380 mm
Weight	7500 g
