Singer 14SH644 - 3) Threading the Right Needle (Green)

14
2) Threading the Lower Looper (Yellow)
• Thread the lower looper as indicated 1 ~ 9 .
• Pass thread from back to the front through the
thread guide 1 .
• Thread the top cover thread
guide by pulling the thread
downward until it slips under
thread guide 2 .
• While holding thread with finger, pass it between
the tension discs and pull thread down to make
certain it is properly located in between the
tension discs 3 .
1
2
3
4
5
9
8
6
1
7
3
2
