16
High Speed Flat Bed Interlock Sewing Machine | Instruction Manual and Parts List
3.9
Stitch Length
Adjustment
Push and hold the button as indi-
cated in Figure 27.
Match the desired stitch length ac
cording to the indication of the ma
chine handwheel (Figure 28).
Push Button
Aligning Mark
Coarse
Fine
The stitch length
adjustment is made
according to the sewing
fabric, differential feed
ratio and other factors.
The stitch length
adjustment must be
made only after the
differential feed ratio
is adjusted.
Important
Note
Figure 27
Figure 28
