Singer 522D - Machine Specification; Motor, Motor Pulley and V-Belt Specifications

4
2.2
2.3
Machine
Specification
Motor, Motor
Pulley and V-Belt
Specifications
Singer
Model
Needle
Gauge
[mm]
Stitch
Length
[mm]
Differential
Rate
Presser
Foot Lift
[mm]
Singer
Needle Cat
Speed
[spm]
Application
Attachment
Device
356-31
5.6
4.4
0.5 ~ 1.3
5.0
3651-06
6,000
Knitting material,
able to adorn
two-sides
1. Plain seaming
2. Seam covering
3. Bottom hemming
364-31 6.4
356-03 5.6
Tape binding
364-03 6.4
356-08 5.6
5,000
Elastic tape or
lace attaching
Tape feeder
Tape feeder
364-08 6.4
356-09 5.6
364-09 6.4
356-01H 5.6
3.3 7.0
Plain seam for
heavy fabrics
364-01H 6.4
356-41 5.6
4.4
5.0
6,000
Knitting material,
able to adorn
two-sides
1. Plain seaming
2. Seam covering
3. Bottom hemming
4. Tape binding
364-41 6.4
Table 1 – Machine Specification 522D (3 Needles / 5 Threads) with Clutch Motor
Machine Speed
[spm]
Motor Pulley Diameter [mm]
50 Hz 60 Hz
6,000 125 105
5,500 115 95
5,000 105 85
4,500 95 80
4,000 85 70
Table 2 - Machine Speed vs. Motor Pulley Diamete
½ HP 2-pole (high speed)
clutch motor
Motor pulley diameter
M type v-belt
Rolled-edge of
under-wear and
T-shirt
Elastic tape or lace
attaching with right
hand fabric trimmer
Singer
Model
Needle
Gauge
[mm]
Stitch
Length
[mm]
Differential
Rate
Presser
Foot Lift
[mm]
Singer
Needle Cat
Speed
[spm]
Application
Attachment
Device
356-31E
5.6
4.4
0.5 ~ 1.3
5.0
3651-06
75/11
3651-06
75/11
3651-06
90/14
6,000
Knitting material,
able to adorn
two-sides
1. Plain seaming
2. Seam covering
3. Bottom hemming
364-31E 6.4
356-03E 5.6
Tape binding
364-03E 6.4
356-08E 5.6
5,000
Elastic tape or
lace attaching
Tape feeder
Tape feeder
364-08E 6.4
356-09E 5.6
364-09E 6.4
356-01HE 5.6
3.3
7
.0
Plain seam for
heavy fabrics
364-01HE 6.4
356-41E 5.6
4.4
5.0
6,000
Knitting material,
able to adorn
two-sides
1. Plain seaming
2. Seam covering
3. Bottom hemming
4. Tape binding
364-41E 6.4
Table 2 – Machine Specification 522D (3 Needles / 5 Threads) with ES DD Motor
Rolled-edge of
under-wear and
T-shirt
Elastic tape or lace
attaching with right
hand fabric trimmer
(for Clutch Motor
only)
