Singer 522D - Parts for 522 D-3 Xx-31, 522 D-3 Xx-31 E

59
High Speed Flat Bed Interlock Sewing Machine | Instruction Manual and Parts List
7.22
Parts for
522D-3xx-31
522D-3xx-31E
1 301S11024 Screw 2
2 W01001 Washer 2
3 30112065 Fabric guide (right) 1
4 30112066 Fabric guide (left) 1
5 30109020 Fabric guide (left) 1
6 S01036 Screw 2
7 30109021 Fabric guide (right) 1
8 W01009 Washer 2
9 30112064 Bracket 1
10 S01011 Screw 2
No. Part No. Description
Qty.
2
2
1
1
1
2
1
2
1
2
For Clutch
Motor
For ES DD
Motor
