No. Part No. Description
23
High Speed Flat Bed Interlock Sewing Machine | Instruction Manual and Parts List
1 301S30001 Shoulder pin 4
2 30111001 Oil level gauge 1
3 30122004 Plug 1
4 30122006 Plug 4
5 30122008 Plug 3
6 30122005 Plug 1
7 H01001 Ring 18 3
8 30112001 Filter 3
9 30112002 Cover 1
10 S01002 Screw M4x6.5 2
11 30122010 Mark 1
13 J900521-xxx Model plate 1
14 30122007 Plug 1
15 S01004 Screw M4x7.8 1
16 W01001 Washer 1
17 S12004 Screw M6x10 2
18 20131063 Sticker 1
20 30122036 Sticker 1
22 30101005 Top cover plate (right) 1
23 L02001 Screw M4x8 8
24 30122003 Gasket 1
25 30101004 Top cover plate (left) 1
26 30122002 Gasket 1
28 1001 O-ring 15x2.65 1
29 S05001 Screw M10x27.5 4
30 W02003 Washer 4
31 30226000 Pin 2
32 P02001 Pin 1
4
1
1
4
3
1
3
3
1
2
1
1
1
1
1
2
1
1
1
8
1
1
1
1
4
4
2
1
7.2
Frame
Components
Qty.
12 R03001 Rivet 2.5x4 2 2
For Clutch
Motor
For ES DD
Motor
