No. Part No. Description
Qty.
25
High Speed Flat Bed Interlock Sewing Machine | Instruction Manual and Parts List
7.3
Cover
Components
1 301010204 Face plate 1
2 301S11001 Screw 1
3 30122101 O-ring 1
4 S01003 Screw M4x12 7
5 3012801 Washer 1
6 30101205 Top cover 1
7 30122012 Plug 1
8 20711002 Sight window 1
9 30122013 O-ring 1
10 30112003 Needle bar cover 1
12 S01004 Screw M4x7.8 3
13 3011208300 Thread take-up guard assembly 1
14 30112083 Thread take-up guard 1
15 30112084 Finger guard 1
16 S01001 Screw 1
17 W01001 Washer 4 3
18 30112085 Bracket 1
19 301S11002 Screw M3x3 1
20 30112006 Thread take-up cover 1
21 301S11002 Screw 2
22 300135 Looper thread guide cover 1
23 W01003 Washer 6 1
24 30111004 Pulley cover 1
25 301S11003 Screw 2
26 301S30002 Screw 1
27 30127001 Flat spring 1
28 S01002 Screw M4x6.5 2
29 S01007 Screw M4x13.5 2
30 30122015 Cushion 2
31 W01004 Washer 5 2
32 S01011 Screw M5x10 2
33 30111003 Eye guard 1
34 S01006 Screw M3x4.5 2
35 W01002 Washer 3 2
36 30112005 Bracket 1
37 W03001 Washer 6 2
38 301S20001 Screw 1
39 30112004 Bracket 1
40 S01004 Screw M4x
7.8 2
41 W01001 Washer 4 2
42 30137005 Sticker 1
43 J900112-001 Singer S cameo 1
44 300136 Front cover 1
45 300657 Bracket 1
46 S01003 Screw M4x12 4
47 J900112-002 Singer resin plate (front) 1
48 J900112-003 Singer resin plate (back) 1
49 R03001 Rivet 2.5x4 4
1
1
1
7
1
1
1
1
1
1
3
1
1
1
1
3
1
1
1
2
1
1
0
0
1
1
2
2
2
2
2
1
2
2
1
2
1
1
2
2
1
1
1
1
4
1
1
4
For Clutch
Motor
For ES DD
Motor
