Singer 522D - Page 32

No. Part No. Description
Qty.
29
1 30102049 Crank shaft assembly 1
2 3010500100 Connection assembly 1
3 S01008 Screw M3.5x13 4
4 30104002 Crank assembly 1
5 S05002 Screw M6x0.75x15.2 1
6 S12002 Screw M3x4 1
7 30103004 Joint 1
8 S12003 Screw M6x7 2
9 S10003 Screw M6x0.75x5 12
10 3012400300 Bushing assembly 1
11 30103006 Bushing 1
12 30103008 Bushing assembly 1
13 3012400400 Bearing 1
14 30125001 Connecting belt gear assembly (lower) 1
15 30103009 Bushing 1
16 B01003 Bearing assembly 1
17 301S11004 Screw 1
18 W02001 Washer 5 1
19 30108001 Cover 1
20 S01004 Screw M4x7.8 2
21 30101015 Machine pulley 0
22 S10009 Screw M6x8 0
23 S12001 Screw M6x8 0
24 30128005 Washer 0
25 S05003 Screw M5x10 0
26 30102003 Shaft 1
27 001001 O-ring 15x2.65 1
28 30135002 Connecting belt 1
29 30126001 Adjusting bar 1
30 30109001 Guide 1
31 3013300600 1
32 114S30001 1
33 W01004 1
34 S01011 4
35 30111033 1
1
1
4
1
1
1
1
2
12
1
1
1
1
1
1
1
1
1
1
2
1
1
1
1
1
1
1
1
1
1
0
0
0
0
0
7.5
Crank Shaft
Components
Energy Saving Direct Drive Motor Assembly
Screw M5X25
Washer
Screw M5X10
Energy Saving Direct Drive Motor Cover
For Clutch
Motor
For ES DD
Motor
High Speed Flat Bed Interlock Sewing Machine | Instruction Manual and Parts List
