Singer 522D - Page 34

No. Part No. Description
Qty.
31
High Speed Flat Bed Interlock Sewing Machine | Instruction Manual and Parts List
7.6
1 30104004 Motion assembly 1
2 S1130114 Screw M8x1x2 2
3 S01011 Screw M5x10 2
4 S08001 Screw M6x0.75x3.5 1
5 S11001 Screw M6x0.75x6 1
6 30103015 Bushing 1
7 30102005 Crank shaft 1
8 3010500300 Connection assembly 1
9 S01003 Screw M4x12 2
10 S01008 Screw M3.5x13 2
11 30104006 Crank assembly 1
12 S05002 Screw M6x0.75x15.2 1
13 30103004 Joint 1
14 S12003 Screw M6x0.75x15.2 3
15 S10003 Screw M6x0.75x5 11
16 30109003 Balance weight 1
17 S10002 Screw M5x5 2
18 30102006 Shaft 1
19 3012400400 Bushing assembly 1
20 30103012 Bushing 1
21 30125002 Connecting belt gear (upper) 1
22 3012400400 Bearing 1
23 30103014 Bushing assembly 1
24 B01005 Bearing 2
25 30102007 Shaft 1
26 30101016 Handwheel 1
27 S12001 Screw M6x8 1
28 S10009 Screw M6x8 1
29 W01004 Washer 5 1
30 S05004 Screw M5X14 1
1
2
2
1
1
1
1
1
2
2
1
1
1
3
11
1
2
1
1
1
1
1
1
2
1
1
1
1
1
1
Main Shaft
Components
For Clutch
Motor
For ES DD
Motor
