No. Part No. Description
Qty.
33
High Speed Flat Bed Interlock Sewing Machine | Instruction Manual and Parts List
7.7
Needle Bar
Components
1 30102008 Needle bar 1
3 301S11005 Screw 1
4 30105005 Needle bar drive link 1
5 30102010 Needle bar crank shaft 1
6 B07001 Needle bearing 1
7 30128006 Washer 1
8 80109004 Block 1
9 30109005 Needle bar guide block 1
10 301S11024 Screw 2
11 S01003 Screw M4x12 2
12 30127003 Latch 1
13 30123002 Sponge 1
14 xxxxxxxx Needle holder assembly 1
16 S10005 Screw M3x3 3
17 xxxxxxxx Needle plate 1
18 301S17001 Screw 2
19 30109006 Needle plate bracket 1
20 S01004 Screw M4x7.8 2
22 30122018 Rubber cushion 1
23 20523003 Oil wick 1
24 30112009 Oil wick retainer 1
25 30102009 Needle bar crank 1
1
1
1
1
1
1
1
1
2
2
1
1
1
3
1
2
1
2
1
1
1
1
For Clutch
Motor
For ES DD
Motor
