No. Part No. Description
Qty.
35
High Speed Flat Bed Interlock Sewing Machine | Instruction Manual and Parts List
7.8
Needle Guard
Components
1 B01001 Eccentric assembly 1
2 S10006 Screw 2
3 3010500600 Connection assembly 1
4 S01008 Screw 2
5 301811024 Screw 1
6 30104007 Crank 1
7 301S12001 Screw 2
8 30126003 Pin 1
9 30102011 Shaft 1
10 30123001 Felt 3
11 20523003 Oil wick 1
12 30128008 Washer 1
13 H05001 Ring 1
14 30122019 Oil seal 1
15 30104009 Needle guard holder assembly (rear) 1
16 S05003 Screw 1
17 W02001 Washer 1
18 S01002 Screw M4x6.5 1
19 30117002 Needle guard (rear) 1
20 30117003 Needle guard (front) 1
21 S01012 Screw 1
22 001001 O-ring 1
23 30110002 Eccentric 1
24 30122017 Oil seal 2
1
2
1
2
1
1
2
1
1
3
1
1
1
1
1
1
1
1
1
1
1
1
1
2
For Clutch
Motor
For ES DD
Motor
