Singer 522D - Page 42

No. Part No. Description
Qty.
39
High Speed Flat Bed Interlock Sewing Machine | Instruction Manual and Parts List
7.10
Feed Dog Holder
Components
6 20123019 Oil wick 1
7 30103022 Bushing 1
8 S10006 Screw M5x6 4
9 30102016 Eccentric pin 1
10 301S12001 Screw 1
11 301109008 Feed bar guide block 1
12 30128011 Washer 1
13 301S17002 Screw 1
14 30109009 Guide (right) 1
15 30103031 Bushing 1
16 30100010 Guide (left) 1
17 L02003 Screw M4x7 2
18 30122020 Oil shield 2
19 30109011 Cover 1
20 30109012 Guide (lower) 1
21 S01005 Screw M4x10 2
22 807002 Needle bearing 1
23 30109013 Block 1
24 30108013 Washer 1
25 30104013 Main feed link 1
26 B07003 Needle bearing 1
27 30103023 Eccentric 1
28 30103024 Regulator 1
29 3010306500 Eccentric retainer 1
30 301S30004 Screw 1
31 30128012 Spring plate 5
32 30103026 Spacer 1
33 301S16001 Nut 1
34 S10002 Screw M5x5 1
35 301S30005 Screw 1
36 30103027 Bushing 1
37 30109014 Guide block 1
38 30128013 Washer 2
39 301S10002 Nut 2
40 301S30006 Screw 1
41 30103028 Bushing 1
42 30129001 Ring 1
43 30105010 Differential feed link 1
44 30109015 Bracket 1
4
5 S01004 Screw M4x7.8 3
46 30102017 Pin 1
47 30127004 Spring 1
48 1004 O-ring 1
49 30128032 Washer 1
50 1105003 Ring 1
51 30103029 Pin 1
52 S12005 Screw M4x4 1
53 3010401500 Crank assembly 1
54 S01012 Screw M2.5x4 1
55 30102018 Shaft 1
56 S10002 Screw M5x5 1
57 30123005 Felt 2
58 30103030 Spacer 1
1
1
4
1
1
1
1
1
1
1
1
2
2
1
1
2
1
1
1
1
1
1
1
1
1
5
1
1
1
1
1
1
2
2
1
1
1
1
1
3
1
1
1
1
1
1
1
1
1
1
1
2
1
For Clutch
Motor
For ES DD
Motor
