No. Part No. Description
Qty.
43
High Speed Flat Bed Interlock Sewing Machine | Instruction Manual and Parts List
1 301S30008 Presser spring regulator bar 1
2 301S16005 Nut 1
3 30127006 Spring 1
4 30104017 Presser bar clamp assembly 1
5 S01003 Screw 1
6 30112016 Link plate 1
7 301S20007 Screw 2
8 3013002400 Presser spring regulator bar assembly 1
9 3010901700 Presser bar clamp guide assembly 1
10 S11025 Screw 2
11 30127008 Spring 1
12 30122022 Oil guard 2
13 001006 O-ring 1
14 30102020 Presser bar 1
15 30112017 Finger guard 1
16 S01006 Screw 1
17 W01002 Washer 1
18 xxxxxxxvxx Presser foot assembly 1
19 301S11010 Screw 1
20 30102021 Presser foot lift shaft 1
21 30127009 Spring 1
22 30108005 Collar (front) 1
23 301S12001 Screw 3
24 30108006 Collar (back) 1
25 30122023 Plug 3
26 30104019 Bell crank (upper) 1
27 301S11011 Screw 1
28 30112018 Link 1
29 301S20008 Screw 2
30 30104020 Bell crank (lower) 1
31 301S20013 Screw 1
32 30102022 Shaft 1
33 30112019 Presser foot lift lever 1
34 S01011 Screw 1
35 30112020 Bracket 1
36 9111004 Screw 2
37 S01016 Screw 1
38 N01002 Nut 1
39 30211006 Presser foot li
ft lever guard 1
1
1
1
1
1
1
2
1
1
2
1
2
1
1
1
1
1
1
1
1
1
1
3
1
3
1
1
1
2
1
1
1
1
1
1
2
1
1
1
7.12
Presser Foot
Components
For Clutch
Motor
For ES DD
Motor
