Singer 522D - Page 48

No. Part No. Description
Qty.
45
High Speed Flat Bed Interlock Sewing Machine | Instruction Manual and Parts List
1 30117005 Spreader 1
2 30104022 Spreader holder assembly 1
3 S01005 Screw M4x7.8 1
4 S01017 Screw M5x14 1
5 30102023 Crank shaft 1
6 30108007 Collar 1
7 201S11033 Screw 2
8 20123019 Oil wick 1
9 3012008 Felt 1
10 O01008 O-ring 3
11 30105013 Crank 1
12 S10003 Screw M4x12 2
13 30126005 Block 1
14 30102024 Shaft 2
15 30128015 Washer 1
16 H05004 Snap ring 1
17 30110007 Eccentric assembly 1
18 S10002 Screw M4x6.5 1
19 30105014 Connection rod 1
20 30104024 Crank assembly 1
21 S05002 Screw 1
22 30126006 Stud screw 1
23 30128032 Washer 1
24 N01002 Nut 2
25 30128018 Washer 1
1
1
1
1
1
1
2
1
1
3
1
2
1
2
1
1
1
1
1
1
1
1
1
2
1
7.13
Spreader
Components
For Clutch
Motor
For ES DD
Motor
