Singer 522D - Page 50

No. Part No. Description
Qty.
47
High Speed Flat Bed Interlock Sewing Machine | Instruction Manual and Parts List
1 3010403200 Lever 1
2 30103040 Spacer 1
3 301S11013 Screw 1
4 3010403100 Crank assembly 1
5 S05005 Screw M5x12 1
6 W01010 Washer 4 1
7 30113001 Thread guide 1
8 S01004 Screw M4x7.8 4
9 30102026 Pipe 2
10 30112021 Bracket 1
11 S01002 Screw M4x6.5 1
12 W01001 Washer 4 1
14 3011300200 Tension control assembly 1
15 30113003 Bracket 1
16 30112022 Thread tension release plate 1
18 3011300500 Tension assembly (medium) 1
19 3011300600 Tension assembly (light) 1
23 30127010 Spring 1
24 301S30009 Screw 1
25 3011300400 Tension assembly (heavy) 3
26 30113007 Thread guide (back) 5
27 30113008 Thread guide (front) 5
28 30103041 Spacer 5
29 301S16006 Knob 5
30 301S30010 Screw stud 5
31 30128016 Tension disc 10
32 30111005 Thread tension disc presser 5
33 30127011 Tension spring (heavy) 3
34 30127012 Tension spring (medium) 1
35 30127013 Tension spring (light) 1
36 30111006 Ratchet 5
1
1
1
1
1
1
1
4
2
1
1
1
1
1
1
1
1
1
1
3
5
5
5
5
5
10
5
3
1
1
5
7.14
Thread Tension
Components
For Clutch
Motor
For ES DD
Motor
