No. Part No. Description
Qty.
51
High Speed Flat Bed Interlock Sewing Machine | Instruction Manual and Parts List
1 3011000800 Thread take-up cam assembly 1
2 S10002 Screw M5x5 2
3 30101020 Bracket 1
4 30102029 Shaft 1
5 30127017 Spring 1
6 001009 O-ring 4.5x1.8 2
7 H05003 Ring 2
8 S10005 Screw M3x3 3
9 30102030 Shaft 1
10 30113017 Screw 1
11 S01001 Screw M4x7 1
12 30112038 Stopper 1
13 30127018 Spring 1
14 301S20010 Screw 1
15 S01007 Screw M4x 13.5 2
16 30128023 Washer 1
17 30101019 Bracket 1
18 30112037 Thread guide 1
19 W02002 Washer 1
20 L02002 Screw M4x10 1
21 30112036 Thread support 1
22 30128019 Washer 1
23 30112035 Looper thread tension bracket 1
24 20613008 Thread guide 1
25 301S11014 Screw 1
26 30113014 Thread guide 2
27 W01012 Washer 2.5 2
28 S01012 Screw M2.5x4 2
29 301S30011 Screw 1
30 20112033 Tension disc 2
31 30127016 Spring 1
32 301S16007 Knob 2
33 S02001 Screw M4x6 2
34 30113016 Thread guide (back) 1
1
2
1
1
1
2
2
3
1
1
1
1
1
1
2
1
1
1
1
1
1
1
1
1
1
2
2
2
1
2
1
2
2
1
35 30113017 Thread guide (front) 1 1
7.16
Looper
Thread Cam
Components
For Clutch
Motor
For ES DD
Motor
