Singer 522D - Page 56

No. Part No. Description
Qty.
53
High Speed Flat Bed Interlock Sewing Machine | Instruction Manual and Parts List
7.17
Lubrication
Components
1 30121012 Oil pipe 1
2 30123010 Felt 1
3 30126008 Pin 1
4 S10002 Screw M5x5 1
5 30123009 Felt 1
6 3012101400 Pipe 1
7 30127019 Pipe holder 1
8 S01004 Screw M4x7.8 1
9 30121007 Oil tube 1
10 30121005 Oil tube 1
11 30121018 Oil tube 1
12 30136002 Oil tube joint 1
13 20129002 Clamp 6
14 30112039 Oil guard 1
15 S01002 Screw M4x6.5 3
16 3012101500 Oil distributor 1
17 N01001 Nut 1
18 30121010 Oil tube 1
19 W01001 Ring 1
20 30121009 Oil distributor 1
21 20122033 Washer 6
22 30121008 Oil tube 1
23 30136004 Oil tube joint 1
24 30129006 Clamp 2
25 301S30013 Screw 2
26 30136003 Oil tube 1
27 301S30012 Screw 1
28 30121017 Oil tube 1
29 30136001 Oil tube joint 2
30 201S30004 Screw 1
1
1
1
1
1
1
1
1
1
1
1
1
6
1
3
1
1
1
1
1
6
1
1
2
2
1
1
1
2
1
For Clutch
Motor
For ES DD
Motor
