Singer 522D - Page 68

65
High Speed Flat Bed Interlock Sewing Machine | Instruction Manual and Parts List
Parts for
522D-3xx-09
522D-3xx-09E (2)
7.25
No. Part No. Description
Qty.
11
12
13
14
15
16
17
18
19
101
111
121
331
141
15 1
161
771
181
191
102
112
122
432
442
1
1
1
1
1
1
1
1
1
1
1
1
3
1
1
1
7
1
1
1
1
1
4
4
30117002 Needle guard (rear)
3011700600 Needle guard (rear) bracket assembly
S05003 Screw M5x10
W02001 Washer
S01002 Screw M4x6.5
30102037 Shaft
30128035 Washer
H05013 Snap ring
30106003 Link assembly
S10002 Screw M5x5
30101036 Bracket
301S11016 Screw
S01004 Screw M4x7.8
30117003 Needle guard (front)
S01012 Screw M2.5x4
30111013 Waste chute (top)
301S30019 Screw
30112048 Waste chute bracket
30103046 Bushing
3011101400 Waste chute assembly (lower)
30111014 Waste chute (lower A)
30111015 Waste chute (lower B)
30128036 Washer
S01005 Screw M4x10
For Clutch
Motor
For ES DD
Motor
