To ensure the best possible operation of your machine, it is
necessary to keep the essential parts clean at all times.
1. Raise the needle to its highest position.
2. Remove the needle plate (1).
3. Remove the bobbin case (2).
4. Clean the feed teeth and shuttle area with the lint brush.
Put one drop of sewing machine oil on the shuttle race as
indicated by the arrows (A,B).
5. Replace the bobbin case with the projection (3)
positioned against the spring (4). Replace the needle
plate.
