Your machine can be used either as a flat-bed or as a free-arm
model.
With the removable storage compartment in position, it
provides a large working surface as a standard flat-bed model.
To take off the removable storage compartment, hold it firmly
with both hands and pull it off to the left as shown. To replace,
slide the removable storage compartment back into place until
it clicks.
With the removable storage compartment off, the machine
converts into a slim free-arm model for sewing children’s
clothing, sleeve cuffs, trouser legs, and other hard-to-reach
places.
WINDING THE BOBBIN
1. Place a spool of thread on the spool pin, and secure it with
the spool pin cap. Pull the thread out from the spool and
place it through thread guides as shown in illustration. It is
very important to make sure the thread is pulled snuggly
into the bobbin winding tension disk, or the bobbin will
not wind properly.
2. Put end of thread through the hole in bobbin as shown.
3. Push bobbin winding spindle to far left position, if it is not
already there. Place bobbin onto the bobbin winding spindle
with end of thread coming from top of bobbin. Push bobbin
winding spindle to the right until it clicks. Hold onto end of
thread.
4. Start machine. Bobbin will automatically stop turning when
completely filled. Push the bobbin winding spindle to the left
to remove bobbin and cut thread.
