SPECIFICATIONS
DC DRIVE MOTOR & REDUCER
Table 2-2
DC drive motor
60min 2min
Output speed (RPM)
1444 677
Output torque (Nm/ft-lb)
5.3 / 3.9 17.1 / 12.6
Voltage (V)
24 24
Current (A)
50 120
Excitation (V)
/ /
Excitation (A)
25 35
Wheel reducer
Speed ratio
45.13:1
Output speed (RMP)
32 15
Output torque (Nm/ft-lb)
176 / 130 569 / 420
Brake torque (Nm/ft-lb)
20
MAJOR COMPONENT WEIGHTS
UNSAFE OPERATION HAZARD
• Do not move heavy
components without
machanical assistance.
• Do not place heavy component
upon instable surface.
Table 2-3
Component Metric (kg) Imperial (lb)
Chassis assembly
973 2145
Pothole cylinder
3
7
Steer cylinder
11 24
Wheel support
13 29
Tire assembly
32
71
DC drive motor & reducer 41 90
Counterweight (at chassis)
114 251
Slewing gear
35
77
