1.2.7 Strider Link Receiver
RF Input Connector: 50 Ohms type N Female, or UHF Female
on request
Sensitivity: Composite: 100µV or less required
for 65dB SNR, left or right channel de-
emphasized, demodulated.
Monaural: 20µV or less required for 65dB SNR
Selectivity:
Composite: 3dB IF bandwidth: +- 125kHz
80dB IF bandwidth: +- 1,2MHz
Monaural: 3dB IF bandwidth: +-90kHz
80dB IF bandwidth: +-1,2MHz
Modulation outputs: Composite: 4Vpp @ 600 Ohms, adjustable
unbalanced
Frequency range: 30Hz to 80kHz
(1 BNC Connector)
Monaural: 0dBm @ 600 Ohms, balanced
Frequency range: 30Hz to 15kHz
(1 XLR Connector)
Stereo decoder outputs:
0dBm @ 600 Ohms, balanced
Frequency range (Left or Right): 30Hz to
15kHz
(2 XLR Connector, 1 Left Signal out, 1
Right Signal out)
Stereo demodulated separation: 40dB or
better.
Power Source: 100/120/220/240VAC 50Hz - 60Hz
15W Max
Dimensions: 1 rack unit (44,45mm)
483mm wide
125mm deep
Shipping Weight: 2,5kg domestic
1-8 System Characteristics
Strider Link Series
SRFStrider-161004A-REV.A
Sinteck Sistemas Eletrônicos Ltda.
01/P/12
