1.2 System Specifications
1.2.1 Strider Link Series - Composite System Characteristics
Frequency Range: 200MHz
300MHz
400MHz
Sub-bands of 5MHz, example: 350-355MHz
Channel Spacing: 25kHz,
50kHz,
100kHz
others on request
Frequency response: +-0.2dB or better, 30Hz to 53kHz
+-0,3dB or better, 30Hz to 75kHz
Distortion:
THD and IMD: 0,2% or less, 30Hz to 7,5kHz
(Typically better than 0,15% at 1kHz)
[Convolved stereo demodulation products greater than 50dB
Below the 100% modulation reference level (400Hz) from 7,5-15kHz]
Stereo Separation: 55dB or better, 50Hz to 15kHz
(Typically 60dB or better)
Signal-to-noise ratio: 65dB or better
(Typically 70dB)
Demodulated, de-emphasized (left or right)
Referenced to 100% modulation
Emision: 500F9
1.2.2 Strider Link Series - Monaural System Characteristics
Distortion: +-0,3dB or better, 30hz to 15kHz
THD and IMD 0,15% or less, 30Hz to 15kHz
(Typically better than 0,1% at 1kHz
Signal-to-noise ratio: 70dB or better
(Typically 75dB)
Referenced to 100% modulation
Operating temperature: -10 C to +70 C
Emission: 110F3 (no subcarrier)
110F9 (with 26kHz control subcarrier)
230F9 (with 67kHz program subcarrier)
