1
1.1 INTRODUCTION
The Strider Link Series RPU&STL, Reportage Link System, Studio Transmitter Link and Auxiliary
Link System is a simple system designed to convey FM program material from a studio site to a
transmitter site like STL use. Also, it can be used like Reportage link when exists the need to
transmit parties, games, events and too many others applications. The Strider Link Series also
simultaneously conveys control and secondary programming subcarriers through MPX inputs.
This equipment may also be used to provide high-quality program transmission in intercity relay
service.
The Strider Link Series of equipment is a family of equiment that can operate in sveral bands from
170MHz through 450MHz. Strider STL Professional Link Series can operate up to 2,5GHz. This
operate manual covers the 170MHz, 200MHz, 300MHz and 400MHz bands of operation and the
various configurations in those bands.
Cards available to 2 different configurations:
The Strider Link system can be configured through cards that can be introduced by the customer
or even configured of it already manufactures internally with these cards. The customer can
choose in working with the basic system without additional card and according to need the cards
can be supplied.
The Strider Transmitter Link can work with a Stereo Generator Card to transmit programs in
Stereo operation. This card is very easy to install when the Strider Link package is bought without
any card.
Also, the second option is the Audio Processor Card, the user can choose to work with this card
and the Stereo Generator Card, the transmittion will have excellent audio quality with these two
cards.
Main Features:
In all of versions there is a LCD Display. RF, audio level, channel and other parameters are shown
on this LCD display. This display offers a very easy method of transmitter parameter monitoring
and a new level of easy for setup and installation, with metering accuracy normally only found on
expensive test equipment.
The FM modulator section in the Strider transmitters employs a fast PLL system and an excellent
VCO for extremely low audio distortion and high stereo performance.
A built in audio modulator provides crystal clear stereo sound and combined with the internal
compressor/limiter a fully compliant “plug and play” all in one link system on the Strider Multiplexx
with cards.
For future compatibility all settings are switchable with on board jumpers. The stereo and/or limiter
settings can be switched in and out to suit the requirements of any external broadcast equipment
you may have now and in the future (in the Strider Multiplexx - all cards installed)
The lightweight universal mains input design ensures a high reliability efficient design compatabile
with any mains system in the world.
1-2 System Characteristics
Strider Link Series
SRFStrider-161004A-REV.A
Sinteck Sistemas Eletrônicos Ltda.
01/P/06
