1.3 System Features
In addition to establishing a new industry standard for performance, the Strider Link Series incorporates
many new and innovative features to aid in the installation, operation and maintenance of a system. Some of
the new features are:
* Very low distortion ceramic IF Filters offering unprecedented selectivity.
* Peak reading meter for all major functions.
* Decade logarithmic true signal strenght meter
* Channel marker and easy channel change.
* Important status functions implemented with LED indicators
* Designed to have a minimum of adjustments for trouble-free operation. Very easy to use.
* Modular construction that provides excellent shielding and at the same time allows easy access to
components.
* Multichannel Option: The Strider Link Series offers a large band of channels, in some models there are 40
Channels.
It is recommended that the manual be studied at least through Section 5 before
attempting to install the system.
1.4 Safety
1.4.1 Mains Voltage
This equipment operates from an AC power source of between 85 and 265V. There are hazardous voltages
present internally. PLEASE OBSERVE CAUTION WITH THE COVER REMOVED.
1.4.2 Swithed Mode Power Supply Hazard
Please note that the power supply units in this equipment is of the switched mode variety and have lethal
voltages present internally. The switched mode supplies are universal input fully approved type. They are non
serviceable modules and should be fully replaced should they fail.
1.4.3 Fuses
Only use fuses with the specified voltage and current ratings as stated on the back panel or pcboard. Failure
to do so may increase the risk of equipment failure, shock and fire hazard.
1.4.5 Radio Frequency
The N type RF power output socket contains RF voltages which may burn or present a shock. Please make
sure that the equipment is connected to an adequately rated load or antenna system while in operation.
1.4.6 Toxic Hazard
This equipment includes RF components that may contain Beryllium Oxide which is a highly toxic substance
that could be hazardous to health if inhaled or ingested. Care should be taken when replacing or discarding
such devices. Seek expert advice from the manufacturer should you physically damage a device that
contains Beryllium Oxide.
The main RF output power module contains Beryllium Oxide.
1.4.7 Other Safety Considerations
Do not operate this equipment in the presence of flammable gases, fumes or liquids
Do not expose this equipment to rain or water.
1
1-9 System Characteristics
Strider Link Series
SRFStrider-161004A-REV.A
Sinteck Sistemas Eletrônicos Ltda.
01/P/13
