Sinteck RPU Link - 2-2 Receiver Front and Rear Panels

2
2-2 Front and rear panels - Strider Receiver Link
Strider Link Series
SRFStrider-161004A-REV.A
Sinteck Sistemas Eletrônicos Ltda.
1 2 3 4 567
8
910
11 12 13 14 15
8 - RF input connector N type 50 Ohms2- Status Leds:
1st: On power
2nd: PLL locked
3nd: Remote ON
4nd: Stereo decoder ON
3 - Remote control sensor (not available) 4 - LCD monitoring display 6-DownButton 5-UPButton 1- Power On/Off - Key 7 - Select Button
9 - MPX output - BNC connector 10 - XLR connector - Mono output 600 ohms 11 - XLR connector - Right signal output 600 ohms 12 - XLR connector - Left signal output 600 ohms 13 - Remote Relay contacts 14 - AC selector switch 15 - Power Socket and fuse
02/P/15
