1.2.3 Strider Link Transmitter - Basic Transmitter system - without cards
Type: Solid State
Direct FM
Frequency Synthesized
Crystal referenced
RF Power Output: 8W tipically, 10W maximum, adjusted in steps of
+-100mW.
RF Output Connector: 50 Ohms N connector type, UHF female on request
Deviation (100% modulation): +-75kHz
+-50kHz (composite)
+-40kHz (monaural)
Frequency Stability: +-5ppm or better (1 or 2 ppm on
request)
Spurious & Harmonic Emission: More than 60dB below carrier level
Modulation Capability: Mono operation and Composite main
subcarrier channels
Modulation inputs: Composite: 0dBm nominal for 75kHz deviation @ 1kHz
adjustable - MPX input BNC connector 10k Ohms unba-
lanced.
Frequency range: 30Hz to 200kHz
(1 BNC connector unbalanced)
Monaural: 0dBm nominal for +-75kHz deviation @ 1kHz
, (internal jumpers for -10dB or +6dB)
XLR connector - balanced electronic floating - 600 ohm
Frequency range: 30Hz to 20KHz
Mono input is made by the LEFT XLR connector
(Internal jumper to 50µs or 75µs pre-emphasis selection)
SCA input: 0dBm nominal for +- 7,5kHz deviation at
57kHz adjustable
Impedance: 10k Ohms
Frequency Range: 50kHz up to 200kHz
BNC connector unbalanced
Power Source: 85 to 265VAC 47-63Hz switched power
supply system, full-range 48W.
12VDC input socket for mobile operation
(Minimum 10,8V and maximum 14V)
Dimensions: 1 rack unit (44,45mm) high
483mm wide
12,5 cm deep
Shipping Weight: 3,5kg
