3-7 Quick guide for installation and use - Strider Transmitter Link
Strider Link Series
SRFStrider-161004A-REV.A
Sinteck Sistemas Eletrônicos Ltda.
STEREO GENERATOR
INSTALLED
STEREO GENERATOR
INSTALLED
The Strider Transmitter Link will find if is installed or not the Stereo Generator Card and
the next message will be:
STEREO GENERATOR
NOT INSTALLED
STEREO GENERATOR
NOT INSTALLED
If every parameters and Cars are in good position and installation, the RF section in the
Strider Transmitter Link enters in operation, the PLL section will be locked, the following
message will be:
PLL LOCKED
The frequency of operation will be shown:
FREQ. 452,50 MHZ
CHANNEL~ 10
FREQ. 452,50 MHZ
CHANNEL~ 10
Note that in this moment if possible to change the frequency of operation on the Strider
Transmitter Link.
REMARK: Make sure that the antenna can respond to all frequencies of the Strider Link,
that it has 5MHz bandwidht at minimum. The Strider Transmitter Link has an intelligent
system to detect any antenna fail, if in the case to change the frequency the alarm fail enters
in operation, do verify the antenna, cables or dummy load that can be presenting some
problem type.
