ASSEMBLY AND OPERATION
3. Cutting a slot (tenon)
• Use the depth stop screw to set the height of the saw-blade (fig. ??) - Fartools -
There needs to be a picture here to show where the screw is. •Use the slide
function for the first cut, and move the work-piece and repeat until most of the
required slot has been cut from the work-piece.
Note: The slot may need to be finished with a chisel (or similar).
Note: Ensure that you return the depth cut screw to it’s original position before
starting regular cuts.
Caution: Never use a “wobble” / “tenon” blade or similar to cut a slot from the work-piece.
TRANSPORTATION
Ensure that the saw is turned off and that the plug is removed from the power supply.
Set and lock the bevel angle to 0° and the mitre angle to 60° to the right.
Lower the saw-head and lock in position.
Lock the sliding rail with the saw-head in position (forward).
Note: Only use the handles provided or the outermost casting on the saw-bed.
-
19
