Loosen the set screws which locks the
reel drive motor shaft and slide the socket
on to the drive on the reel, then retighten
the clutch (outer) set screw.
Align the clutch set screw with the
clutch lock-out set screw and tighten the
clutch lock-out (inner) set screw on to the
flat of the shaft.
Feed the grinding head up until the
grinding stone just touches the reel at the
large end then back off about .020.
WARNING-Make sure that all clamps are
tight. Loose clamping may cause damage
or injury.
