While holding the reel blade against
the blade stop, turn the grinding stone to
see if you have the same contact as on
the left end of the reel. If you get the
same contact while infeeding the grinding
stone up or down .010, go to Section 5.9,
otherwise continue on to the next step.
Turn the ratchet handle in or out until
you have consistent contact on both ends
of the reel. You will have to remove the
locating pin if you need to move the post
back. When you are done with this reel,
make sure you replace the pin and
position the post against it. This will reset
the posts parallel.
INFO-This procedure may not be accurate
If the reel blades have some relief left.
Make sure the Auto Infeed is off.
DANGER-Always close shield or wear
safety glasses and face shield when
grinding! Stay clear of grinding stone when
turning grinder on!
