Appendix B
Specifications
WL-108/WL-109 Wireless ADSL Router
Model WL-108/WL-109 Wireless ADSL Router
ADSL Interface T1.413, G.DMT, G.lite, multi-mode
Dimensions 189mm(W) * 122mm(D) * 33mm(H)
Operating
Temperature
0° C to 40° C
Storage
Temperature
-10° C to 70° C
Network Protocol: TCP/IP
Network Interface:
4 * 10/100BaseT (RJ45) LAN connection
1 * RJ11 for ADSL line
LEDs 12
Power Adapter 15 V DC External
Wireless Interface
Standards IEEE802.11b, IEEE802.11g WLAN, JEIDA 4.2,
roaming support
Frequency 2.4 to 2.4835GHz (Industrial Scientific Medical Band )
Channels Maximum 14 Channels, depending on regulatory
authorities
Modulation CCK, DQPSK, DBPSK, OFDM/CCK
Data Rate Up to 54 Mbps
Coverage Area Indoors : 15m @54Mbps, 120m @6Mbps or lower
Outdoors : 40m @54Mbps, 300m @6Mbps or lower
WEP 64Bit, 128Bit
Output Power 13dBm (typical)
Receiver Sensitivity -80dBm Min.
