8. For the assigned channels, operate their mapped joysticks, dials, switches, and
buttons on the handheld ground station to confirm if they are working normally.
6.4.2 Gimbal Pitch and Yaw Rotation (Taking an example of Dial Control)
Below is suggested channel mapping settings for testing, customers are free to
assign channel mappings as required through SIYI TX app.
⚫ Channel 7 = Left Dial (Reversed)
⚫ Channel 8 = Right Dial
⚫ Channel 12 = Any Button
In SIYI PC Assistant, map “Yaw” function to channel 7 and “Pitch” to channel 8,
“Center” to channel 12.
Then, if you operate the left dial, gimbal will rotate on yaw axis. If you operate the
right dial, gimbal will rotate on pitch axis. Press the button, gimbal will center itself
automatically.
Mark
Hold the dial from its center position, gimbal will keep rotating unless there was a physical
limit. Farther you hold it away from center, faster gimbal rotates.
