MK15 User Manual V1.4
10
2023 SIYI Technology, All Rights Reserved
1.2.2 Button / Switch Types and Default Channel Definitions
MK15 remote controller comes with 13 physical channels and 16 communication
channels in total. Communication channel 10 to 14 are also PWM channel 1 to 5
in default.
Channel
No.
Physical Channel Type
Default Mapping
Remark
1
Aileron
Joystick J1
2
Elevator (Mode 2)
Joystick J2
3
Throttle (Mode 2)
Joystick J3
4
Rudder
Joystick J4
5
3-Stage Switch SA
6
3-Stage Switch SB
7
3-Stage Switch SC
8
Button A
9
Button B
10
Button C
PWM 1
11
Button D
PWM 2
12
Left Dial LD
PWM 3
13
Right Dial RD
PWM 4
14
PWM 5
15
Searchlight A
Gimbal Pitch
16
Searchlight B
Gimbal Centering
