MK15 User Manual V1.4
23
2023 SIYI Technology, All Rights Reserved
Green Blinks (every 3/5 second): Receiving 50% to 75% data package.
Green Blinks (every 3/10 second): Receiving 25% to 50% data package.
Green Blinks (every 1/25 second): Receiving less than 25% data package.
Green-Red Blinks: Air Unit high-temperature alert, level one.
Green-Red Blinks: Air Unit high-temperature alert, level two.
Green-Red Blinks: Air Unit high-temperature alert, level three.
Slow Red-Green-Yellow Blinks: Image transmission is starting.
1.5.2 Air Unit Indicator
Solid Red: No communication between transmitter and Air Unit.
Fast Red Blinks: Transmitter is binding to Air Unit.
Slow Red Blinks: Firmware does not match.
Triple Red Blinks: Image transmission initialization failed.
Yellow Blinks: Low voltage alert (voltage input from PMU is lower than 12V).
Solid Green: Perfect communication, 100% data package received.
Green Blinks: Blinking speed indicates MK15 system’s signal strength. The faster it
blinks, the worse the signal is.
Slow Green Blinks: 95% to 99% data package received.
Green Blinks (every 3/5 second): 50% to 75% data package received.
Green Blinks (every 3/10 second): 25% to 50% data package received.
Green Blinks (every 1/25 second): less than 25% data package received.
Green-Red Blinks: Air Unit high-temperature alert, level one.
