SIYI MK15 User Manual

MK15 User Manual V1.4
17
2023 SIYI Technology, All Rights Reserved
Dimensions
106 x 25 x 41 mm
Weight
108 g
Working Temperature
-10℃ ~ 50℃
Air Unit HDMI Input Converter
(Optional, Packed with Enterprise HDMI Combo)
Video Input
Micro HDMI
Video Output
Ethernet
Working Voltage
12 V
Power Consumption
3 W
Video Recording
Resolution
1080p (1920*1080) @ 30 fps
720p (1280*720) @ 30 fps
Recording Bitrate
12 Mbps (H265 codec)
File Storage Format
FAT32
Video Recording Format
H265
Supported TF / SD Card
Type
MicroSD Class10
Less than 32GB
Dimensions
42 x 41 x 11 mm
Weight
26 g
Working Temperature
-10℃ ~ 50℃
R1M Recording FPV Camera
(Optional)
Video Output
Ethernet
Image Sensor
1/2.9 Inch, 2 MP
FOV
Diagonal: 90°
Horizontal: 80°
Working Voltage
12 V

SIYI MK15 Specifications

General

Frequency	2.4GHz
Channels	16
Operating System	Android
Operating Frequency	2.4 GHz
Low-Voltage Alarm	Yes
Operating Voltage	7.4V
Video Transmission	1080p
Charging Port	USB Type-C
Ports	HDMI, USB, Micro SD
Transmission Range	8-15 km (depending on environment)
Endurance	6-8 hours
Compatibility	SIYI cameras and drones
