distance between these parts and the structure parts.
5. The two air unit antennas should be placed away from each other for at least
50 mm distance. And try your best to avoid any kinds of obstruction between
the ground unit and the aircraft during flight.
6. Please be very careful with the antenna wire’s SMA connectors and its solder
connectors. Do not drag them or bend them in case of any damage. To adjust
the position of the antenna, please always try to bend the middle part of the
antenna feeder wires.
CAUTION
As shown in the picture below, for small and medium-sized multi-rotor drones, the air unit
antenna should be placed downward perpendicular to the arm to keep the flat surface of the
antenna facing the direction of the remote controller.

SIYI MK15 Specifications

General

Frequency	2.4GHz
Channels	16
Operating System	Android
Operating Frequency	2.4 GHz
Low-Voltage Alarm	Yes
Operating Voltage	7.4V
Video Transmission	1080p
Charging Port	USB Type-C
Ports	HDMI, USB, Micro SD
Transmission Range	8-15 km (depending on environment)
Endurance	6-8 hours
Compatibility	SIYI cameras and drones
