9 IF-105 user interface
9.1 General information
IF-105 is the user interface for the internal control unit of SKF Maxilube change over valve unit.
Lubrication programming, alarm resetting and lubrication event monitoring can be performed with the user in-
terface.
9.2 Design
The IF-105 user interface includes a display(1), LED-signals for lubrication lines and pressurisation (2), brows-
ing buttons (3), a setting / function button SET (4) and LED-signals for lubrication channels (5).
5
1
2
3
4
