4. Assembly instructions Page 18
EN
Attach the piston pump to the intended mounting
location using appropriate fastening materials (e.g.,
bolts, washers, and nuts).
Warning!
During assembly and especially when
drilling, always pay attention to the
following:
o Existing supply lines must not be
damaged by assembly work.
o Other units must not be damaged by
assembly work.
o The product must not be installed
within range of moving parts.
o The product must be installed at an
adequate distance from sources of
heat.
o Maintain safety clearances and comply
with local regulations for assembly and
accident prevention.
4.3. Compressed air connection
(pneumatically operated piston
pump)
The compressed air line must be connected to the
piston pump in such a way that no forces can be
transferred to the assembled piston pump (stress-
free connection).
Danger!
Ensure that the main air valve is closed
before connecting the piston pump to the
compressed air supply.
Warning!
The maximum primary air pressure
indicated for operation of the piston
pump must not be exceeded.
The compressed air to be used here must comply
with at least quality class 5 as defined by  DIN ISO
8573-1:
o Max. particle size 40 μm
o Max. particle density 10 mg/m³
o Pressure dew point 7°C
o Water content max. 7800 mg/m³
o Residual oil content max. 25 mg/m³
Through the use of the appropriate compressed air
quality class, compressed air preparation can be
optimized and machine downtime and higher
maintenance costs avoided.
The pneumatic connection is established via the
connector labeled P1 on the piston pump's housing.
See the  technical documentation for more
information about the compressed air connection.
If no documentation is available, you can
request the documentation directly from
SKF Lubrication Systems Germany AG.
4.4. Hydraulic connection (hydraulically
operated piston pump)
The hydraulic line must be connected to the piston
pump in such a way that no forces can be
transferred to the assembled piston pump (stress-
free connection).
Danger!
Ensure that the hydraulic supply is
depressurized before connecting the
piston pump to the hydraulic supply.
Warning!
The maximum hydraulic oil pressure
indicated for operation of the piston
pump must not be exceeded.
The hydraulic connection is established via the
connector labeled P1 on the piston pump's housing.
See the  technical documentation for more
information about the hydraulic connection.
