1 - 2 QuickCollect
User Manual
No Submersion/Immersion
This equipment is IP67-rated. It is dust-tight and resistant to accidental immersion in
liquid up to a depth of 1 m (39.37 in.) for up to 30 minutes. If the instrument is
subjected to more extreme conditions, this may result in adverse operation.
Avoiding Damage and Injury
To avoid costly damage to the instrument or injury caused by the instrument falling,
place the instrument on a solid stable surface when not in use and do not place any
heavy objects on it.
Use a damp, clean cloth for cleaning. Do not use cleaning fluids, abrasives or aerosols.
These might cause damage, fire or electrical shock.
Do not open the device cover in a hazardous area or in locations where contact with
water or other contaminants may occur.
About This Manual
This manual provides information on the setup and use of the SKF QuickCollect Sensor
Bluetooth® instrument (part no. CMDT 390). In this manual, the sensor instrument is
commonly referred to as the QuickCollect sensor, or just the sensor.
Please refer to the relevant user manual to use the QuickCollect sensor within a
DataCollect question:
For iOS devices, refer to DataCollect CMDT 3900 iOS User Manual P/N 15V-090-
00053- Chapter Completing Standalone Collections.
For Android devices, refer to DataCollect CMDT 3900 Android User Manual P/N
15V-090-00052-100 Chapter Completing Standalone Collections.
As you use this manual, you will discover certain conventions used:
Bold type is used to indicate text that appears in a menu, window or dialogue
box.
Italics are used to emphasise important information.
is used to indicate notes to the reader.
Step-by-step procedures are sequenced using bullet points, •.
