Each side is tallied up and displayed under
Totals  .
Counter Channels can be cleared or, If you have
a paper  tape printer,  printed under  Options  .
Guns and Trip can be printed separately.
4.4.1 Pattern Counter Channels
In addition to standard counter channels, each system can be customized
to track specific patterns by total distance. These channels are in addition
to the standard counters, and may better match the billing and reporting
requirements in a given locale.
Standard counter channels and pattern counter channels both count at the
same time, and should not be combined. For example, an advanced
Double Solid  counter counts distance traveled when Material #1 and
Material #2 are turned on in solid. The standard #1 and #2 counter
channels will each individually count distance as well. You cannot combine
the standard #1 channel and the advanced Double Solid counter channels,
since that would be double-counting.
Some pattern counter examples:
➢ When Gun 1 and Gun 2 are in solid, count into Double Solid.
➢ When Gun 1 or Gun 2 are in skip, but not both, count into Single Skip.
➢ When Gun 1 is solid and Gun 2 is skip, count into Skip-Solid.
➢ When the width of Gun 4 is 8", count into White 8".


