To begin a
Distance Calibration
, align the
vehicle with the start of a calibration course
and then select
Begin Calibrating
.
A
calibration course
is a pre-measured distance
for the vehicle to drive. Make your own easily
by measuring out a distance of 1,000 feet or
greater.
Drive the distance of the course.
Note that the
Old Calibration Distance
number
is likely incorrect. It is useful to see to ensure
that motion pulses are being received, but is
not the actual distance traveled.
Correct the distance measured, to the actual
distance traveled.
For example, if your course was 1000', and the
measured distance was 932', you would change
932' to be 1000'.
Save Calibration
to complete this process.
If there was an error, verify the motion sensor is
installed correctly.
The motion pulse source should provide
between 2 pulses per foot and 20 pulses per
foot.
SC-12 Road Marking Control System - Installation and Operation Manual
36
