Date: 2022-09-26 Page 21 of 48
Operation and Installation CD401MR-SC
Rotation
The NMEA sentence ROT is supported for receiving information about the rotation. A
steady arrow is added on the text line to indicate which direction the bow turns.
• A positive received value indicates that bow turns to starboard and an arrow to the
right is displayed.
• A negative received value indicates that bow turns to port and an arrow to the left
is displayed.
• A value of zero indicates no rotation and no arrow is displayed.
Values below 99.9 are displayed with one decimal. Values above 100 are displayed with
no decimals. Maximum value to display is +/- 999
o
/min.
screen:
Runtime screen:
