Operation and Installation CD401MR-SC
Date: 2022-09-26Page 44 of 48
APPENDIX 3.
____________________________________________________________________
The Compact Display can be set up for one of the following systems:
LR Speed Repeater Backplate with 2m 12 core cable
MR Multi Repeater Backplate with 2m 12 core cable
MB Multi Repeater
Backwards
Backplate with 2m 12 core cable
E1 (EML124 Compact) EML. Single axis
STW. Control unit
Backplate with 10m 17 core cable.
With Electronic unit JB60CD
E2 (EML224 Compact) EML. Dual axis
STW. Control unit
Backplate with 10m 17 core cable.
With Electronic unit JB60CD
EB (EML224 Compact) EML Dual axis
STW. Control
unit. Backwards
Backplate with 10m 17 core cable.
With Electronic unit JB60CD
D1 (DL1 Compact) DL1. Single axis
STW. Control unit
Backplate with 10m 17 core cable.
With Electronic unit JB60CD
CU (DL1 Multi) DL1 Multi. Single
axis STW Control
Unit
Backplate without cable.
LAN communication with
Electronic unit JB70D1
• Speed Repeater: A simple repeater for speed in single and dual axis and trip.
Limited functionality.
• Multi Repeater: A comprehensive repeater for many of the most common
used NMEA messages. Functions also for user dened messages.
• : As above, but the speeds are shown in opposite
direction.
• Single Axis EML: Primary display for EML224 Single axis Compact speed
logs showing longitudinal speed values produced by the sensor.
• Dual Axis EML: Primary display for EML224 Dual axis Compact speed logs
showing both longitudinal and transverse speed values produced by the sensor.
• : Primary display for EML224 Dual axis Compact
speed logs showing both longitudinal and transverse speed values produced by
the sensor, but can be connected to an external switch for showing the speeds
in opposite direction.
• Single Axis DL1 Compact: Primary display for DL1 Single axis Compact
speed logs showing longitudinal speed values produced by the sensor.
• Single axis DL1 Multi The same electronics is used for the CD402CU-SC.
