Operation and Installation CD401MR-SC
Date: 2022-09-26Page 34 of 48
NMEA
Sentence
Description Parameter
Name
Screen
name
Speed
VBW Longitudinal Water Speed
STWWL will have one decimal for all speed
values
STW2L always display speed below 10
knots with two decimals and speed from 10
knots and above with one decimal.
STWWL
STW2L
STW
Transverse Water Speed
STWWT will have one decimal for all
speed values
STW2T always display speed below 10
knots with two decimals and speed from 10
knots and above with one decimal.
STWWT
STW2T
STW
Transverse Water Speed, Aft STWWA STW
Longitudinal Ground Speed
SOGBL will have one decimal for all speed
values
SOG2L always display speed below 10
knots with two decimals and speed from 10
knots and above with one decimal.
SOGBL
SOG2L
SOG
Transverse Ground Speed
SOGBT will have one decimal for all speed
values
SOG2T always display speed below 10
knots with two decimals and speed from 10
knots and above with one decimal.
SOGBT
SOG2T
SOG
Transverse Ground Speed, Aft SOGBA SOG
VHW Speed Through Water in knots, relative STW-R STW-R
VTG Speed over Ground in knots, relative SOG-R SOG-R
XDR Water Speed direction, displayed as arrow
on screen
- -
Distance
VLW Water-track Distance since reset TRIPW TRIPW
Water-track Total distance TOTLW TOTLW
Bottom-track Distance since reset TRIPB TRIPB
Bottom-track Total distance TOTLB TOTLB
Heading. VHW Heading, degrees, true HDW-T HDG.T
Heading, degrees, magnetic HDW-M HDG.M
VTG Heading (Course Over Ground), degrees,
true
COG-T COG.T
Heading (Course Over Ground), degrees,
magnetic
COG-M COG.M
THS Heading, degrees, true THS HDG.T
HDT Heading, degrees, true HDT HDG.T
HDM Heading, degrees, magnetic HDM HDG.M
HDG Heading, degrees, magnetic HDG HDG.M
Rotation
ROT Rate of Turn in degrees/minute ROT ROT
Pitch and
roll
XDR Pitch PITCH PITCH
Roll ROLL ROLL
