Storage compartment on the front passenger side
Fig. 112 Open storage compartment / close storage compartment and
open air supply
Read and observe
and on page 88 first.
The storage compartment is equipped with an interior light (this is illuminated
when the parking lights / low beam are switched on), a pen holder and an air
outlet.
Storage compartment
›
To open, press the
--
button. The cover folds in the direction of arrow
1
» Fig. 112.
›
To close, swivel the cover in the direction of arrow
2
until it audibly clicks
into place.
Air supply
›
To open, turn the rotary switch until it stops in the position
» Fig. 112.
›
To close, turn the rotary switch until it stops in the position .
Opening the air supply when the air conditioning system is switched on allows
cooled air to flow into the storage compartment.
Opening the air inlet when the air conditioning system is on causes fresh or in-
terior air to flow into the storage compartment.
The maximum permissible load of the storage compartment is 3 kg.
Storage compartment under the front passenger’s seat
Fig. 113
Opening the storage compart-
ment
Read and observe and on page 88 first.
›
To open, pull the handle in direction of arrow
1
pull and open the compart-
ment in the direction of arrow
2
» Fig. 113.
›
To close, pull the handle in the direction of arrow
1
and hold this against the
direction of arrow
2
until the storage compartment closes.
The maximum permissible load of the storage compartment is 1.5 kg.
Storage compartments for umbrellas
Fig. 114
Storage compartment for an
umbrella - view example in the
left door
Read and observe and on page 88 first.
The storage compartments in the front doors » Fig. 114 can be used to store an
umbrella.
94
Using the system
