SkyHopper PRO - Appendix A: Specifications

14
Appendix A - Specicaons
Radio and Modem
Frequency 2.4GHz (ISM)
900MHz (ISM) - Optional
5.8GHz (ISM) - Optional
Antenna’s Connectors MMCX (X2)
TX Power Control 50dB
RX Dynamic Range 70dB
Sensitivity Max –101dBm
Radio Access Method OFDM - TDMA
Duplexing TDD
Conguration MIMO 2X2
Channel BW 4.2MHz / 8.4MHz
Frequency Resolution 0.25MHz
Diversity Support TX & RX Diversity
FFT Supported 512
32 – 2048 upon request
FEC method Turbo Code
Modulations QPSK / 16QAM
Throughput Congurable up to 6 Mbps
Synchronization 1PPS sync input
Encryption AES-128 bit
Environmental
Temperature Range Operating Storage
-10°C to 40°C -50°C to 85°C
Humidity 5 to 95%
Interfaces
Data Ethernet, RS232
Full Ethernet Protocol Transparency IP,TCP,UDP, RTP, HTTP
Broadcast, Multicast, Unicast
Ethernet, VLAN, VPN
Serial Data RS232
USB Optional
Dimensions [HxWxD] mm [HxWxD] inch
26 x 54 x 74 1.0 x 2.1 x 2.9
Weight Grams Ounce
105 gr. 3.7 oz.
