16
Appendix B - Mechanical Drawings
54.01
75.30
42
4.50
6.50
2 x M2x0.4 - 6H
3
MAX SCREW DEPTH
2.5
13
32.1
42.9
59.7
9.9
10.5
11.1
10.3
1
3
4
2
4.20
45 5
51.60
22.50
18.70
3 x M2.5x0.45 - 6H
3.50
42
28.9
5.2
12.8
16.1
6.50
4.50
M2x0.4 - 6H
3
MAX SCREW DEPTH
2.5
3 TYP. 3
5
NOTES:
1. APPLICABLE STANDARDS / SPECIFICATIONS:
ASME Y14.5M-1994, DIMENSIONS AND TOLERANCES.
ASME Y14.38, ABBREVIATIONS.
ASME Y14.16aM OR Y14.6, SCREW THREADS.
2. THE PART AND FINISH SHOULD BE COMPLIANCE WITH THE "EUROPEAN DIRECTIVE FOR RESTRICTIONS OF
THE USE OF CERTIAN HAZARDOUS SUBSTANCES IN ELECTRONIC EQUIPMENT" (RoHS DIRECTIVE 2002/95/EC).
1
CONNECTOR: CAT5, RECEPTACLE
2
CONNECTOR: MOLEX, CLICK MATE SERIES, 6 PINS, RECEPTACLE (P/N: 5023860670)
3
CONNECTOR: MOLEX, MICRO USB, 5 PINS, RECEPTACLE (P/N: 476100001)
4
CONNECTOR: JST, ZE SERIES, 4 PINS, MALE (P/N: 5023860670)
5
CONNECTOR: MCX SERIES, RECEPTACLE
X3
578 246 13
E
D
C
F F
D
B
A
E
C
DRAWN
APPV'D
FINISH:
DEBURR & BREAK SHARP EDGES
NAME
SIGNATURE
DATE
MATERIAL:
THE INFORMATION CONTAINED IN THIS DRAWING IS THE
SOLE PROPERTY OF MOBILICOM. ANY REPRODUCTION IN
PART OR WHOLE WITHOUT THE WRITTEN PERMISSION OF
MOBILICOM IS PROHIBITED.
REVISION:
TITLE:
DWG NO.
SCALE:1:1
SHEET 1 OF 1
A3
FIRST ANGLE PROJECTION
ILAN B.
1/11/2017
05-0007-00
SKY HOPPER PRO UNIT
INTERFACE CONTROL
A-02
SIZE:
1/11/2017
ILAN B.
UNLESS OTHERWISE SPECIFIED
UNITS:
GENERAL
SURFACE FINISH:
LINEAR:
ANGULAR:
GENERAL TOLERANCES:
MM
Ra 1.6
