Skyjack SJ40 T+ - Page 93

SJ40 T+, SJ45 T+, SJ61 T+, SJ66 T+ 213201ACA
93
Technical diagrams Section 7 – Technical Diagrams and Specifications
Dimensions - SJ66 T+ (continued)
61°
360°
63°
170°
1.11m
(4 ft)
0.65 m
(2 ft)
0.17 m
(1 ft)
1.60 m
(63 in)
2.44 m
(8 ft)
1.93 m
(6 ft 4 in)
5.05 m
(16 ft 4 in)
1.33 m
(4 ft 6.5 in)
2.81 m
(9 ft 2.5 in)
1.62 m
( in)
2.44 m / 1.83 m
(96 in / 72 in)
0.91 m
(36 in )
0.36 m
(14.25 in)
0.06 m
(2.5 in)
